ATEX Z22-CERTIFIED VACUUM CLEANER FOR DUST AND SOLIDS
High antistatic filtration capacity, spacious collection tank, side channel turbine, ATEX Z22-certified: these are the features that make the TS75 the ideal vacuum cleaner to vacuum dust and solids even mixed with liquids in ATEX Z22-classified areas. A compact structure and convenient integrated manual filter cleaning system to ensure efficient certified cleaning and maintenance for machines and workplaces.
In the version with the PN filter cleaning system, vacuuming remains constantly efficient thanks to the pneumatic counter-current cleaning system that allows for safe, continuous vacuuming.
| TS75AFZ22 | TS75Z22 | TS75AFPNZ22 | TS75PNZ22 | |
| ATEX zone | 22 | 22 | 22 | 22 |
| Marking | Ex II 3D Ex tc IIIB T135°C X Dc | Ex II 3D Ex tc IIIB T135°C X Dc | Ex II 3D Ex tc IIIB T135°C X Dc | Ex II 3D Ex tc IIIB T135°C X Dc |
| Voltage (V-Hz) | 400-50 3~ | 400-50 3~ | 400-50 3~ | 400-50 3~ |
| Power (kW) | 7,5 | 7,5 | 7,5 | 7,5 |
| Continuous waterlift (mmH₂O) | 2700 | 3200 | 2700 | 3200 |
| Max waterlift (mmH₂O) | 3200 | 4000 | 3200 | 4000 |
| Airflow (mᶟ/h) | 700 | 530 | 700 | 530 |
| ø Suction inlet (mm) | 80 | 80 | 80 | 80 |
| Noise level dB(A) (EN ISO 3744) | 76 | 76 | 74 | 76 |
| Capacity (l) | 100 | 100 | 100 | 100 |
| Dry primary filter | Star | Star | Cartridge | Cartridge |
| Dry media, class | Polyester ANT M | Polyester ANT M | Polyester ANT M | Polyester \ANT M |
| Dry surface, diameter (cm²-mm) | 49.000-500 | 49.000-500 | 80.000 | 80.000 |
| Load on filter (m³/m²/h) | 143 | 108 | 88 | 66 |
| Filter cleaning system | Manual | Manual | Pneumatic, reverse air pulse | Pneumatic, reverse air pulse |
| Dimensions (cm) | 66x118x175h | 66x118x175h | 66x118x175h | 66x118x175h |
| Weight (kg) | 170 | 170 | 180 | 180 |
ABSOLUTE FILTER
STAINLESS STEEL FILTER CHAMBER AND CONTAINER
AVAILABLE WITH FORK LIFT INTAKES
PNEUMATIC FILTER CLEANING SYSTEM
