MS FIXE

WALL-MOUNTED INDUSTRIAL VACUUM CLEANER FOR LOCALISED DISCHARGE



The AS FIXE vacuum cleaner is a collection unit that can either be installed on a floor-based frame or wall mounted. The vacuum cleaner, developed alongside large manufacturing industries, transports the collected material and discharges it via a weighted flap discharge system in a defined point with big bags or containers. Other discharge systems, even automatic ones, further simplify and speed up the operations.

A powerful 3 kW maintenance-free turbine and a primary star filter, with manual cleaning system, guarantee continuous efficiency.

Completely bespoke, thanks to the various discharge systems available and to the different installations.



  • Vacuum relief valve included
  • Extreme installation versatility
  • Maintenance-free turbine, suitable for continuous 24/7 work
  • Manual filter cleaning

  • For dusts and solids

  • For continuous use

Technical Features
MSFIXE
Voltage (V-Hz)400-50 3~
Power (kW)3
Depres in continuo (mmH₂O)2700
Max waterlift (mmH₂O)3200
ø Suction inlet (mm)80
Discharge system Discharge flaged with cone
Dry primary filter Star
Dry Media, classPolyester - L
Airflow (mᶟ/h)318
Dry surface diameter (cm²-mm)30.000-500
Filter cleaning system Manual
Noise level dB(A) (EN ISO 3744)75
Dimensions (cm)58x55x175h
Weight (kg)60
Optional

FRAME FOR FLOOR FIXING
